Victron GX LTE 4G-A Cellular Modem f/GX Devices - North America Only

The GX LTE 4G-A Cellular Modem is an essential accessory for marine enthusiasts looking to keep their GX devices connected while on the water. Designed specifically for North America, this robust modem ensures reliable mobile internet access, enabling seamless monitoring and management of your marine systems through the Victron Remote Management (VRM) portal.

Advanced Connectivity for Your Marine Systems

The GX LTE 4G-A Cellular Modem supports 2G, 3G, and 4G technologies, providing versatile internet connectivity for a wide range of marine environments. Whether you're cruising the coastline or anchored in a remote harbor, this modem ensures your GX device stays online, allowing for real-time system monitoring and management.

Built-in GPS Receiver for Enhanced Tracking

Equipped with a built-in GPS receiver, the GX LTE 4G-A enables precise location tracking and geo-fencing through the VRM Portal. For improved tracking capabilities, you can install the optional active GPS antenna.

Optional Accessory: GSM900200100 - Active GPS Antenna for GX GSM.

Seamless GX Device Compatibility

The GX LTE 4G-A is compatible with all GX devices running Venus OS v2.60 or newer. This ensures broad compatibility across various GX models, making it a versatile choice for different marine setups.

SIM Card Requirements

A Mini-SIM card is required to activate cellular connectivity. Ensure your SIM card supports both 1.8V and 3V for optimal performance.

When to Choose a Mobile Router Instead

The GX LTE 4G-A is ideal for providing internet connectivity exclusively to your GX device. If your marine setup requires internet access for multiple devices such as laptops, smartphones, or tablets, consider using a mobile router to share the connection efficiently.

Antenna Options for Optimal Signal Strength

Included with the GX LTE 4G-A is a compact indoor LTE antenna, perfect for maintaining a strong signal within your vessel. For enhanced range and reliability, Victron offers an outdoor LTE antenna.

Optional Accessory: GSM900100400 - Outdoor 4G GSM Antenna.

Technical Specifications

General Specifications
Region	North America
Used Module	SIMCom, SIM7600A
Supported LTE Bands	2, 4, 12
Supply Voltage Range	8 - 70VDC
Power Draw	2.5W during data transfer / <1.0W idle / +0.4W with GPS enabled
Operating Temperature	-40 to +50°C (-40 to 120°F)
Dimensions (L x W x H)	106 × 42.5 × 22mm
Weight	0.08kg (0.177lbs)
Power Cable	1.4m with inline fuse holder, terminal block, and 10mm ring terminals
Inline Fuse	T3.15A250V

Communication Specifications

Feature	Details
USB Communication Port	Fixed 1.0m cable with USB-A connector (connects to the GX device)
LTE Antenna Connector	Type SMA Female (optional GSM900100400 Outdoor Antenna)
GPS Antenna Connector	Type SMA Female (optional GSM900200100 GPS Antenna)
GNSS Support	GPS, Beidou, GLONASS, GALILEO, QZSS
SIM Card	Regular Mini SIM (supports both 1.8V and 3V)
Data Transmission (LTE Cat-1)	Download: 10 Mbps / Upload: 5 Mbps
Data Transmission (3G HSPA+)	Download: 42 Mbps / Upload: 5.76 Mbps
Data Transmission (2G EDGE)	Download & Upload: 236.8 Kbps
Data Transmission (2G GPRS)	Download & Upload: 85.6 Kbps
Status Indicator	Blue LED

Installation & Dimensions

• Dimensions: 106 × 42.5 × 22mm
• Weight: 0.08kg (0.177lbs)
• Power Cable Gauge: 0.5..1.5mm² / AWG 28..16 (or use supplied power cable)
• Recommended Fuse Size: 500mA @ 12V / 250mA @ 24V / 100mA @ 48V (or use supplied inline fuse)

What's Included

• GX LTE 4G-A Cellular Modem (with integrated USB cable)
• GSM 2G/3G/4G Mini-Rod Antenna (indoor use)
• DC Power Cable (with inline fuse and terminal block)

Compliance & Standards

• Safety: EN 60335-1, EN 60335-2-29, EN 62368-1
• Emission / Immunity: ECE R10-5
• Quality Management: EN 9001:2015

Support & Resources

Please contact your dealer for any returns, repairs, or support issues related to this product.

Quick Guide (PDF)

Owner's Manual (PDF)

Product Videos
