Tekonsha ModuLite HD Protector w/Integrated Circuit Overload Protection 5-Flat Connector f/Backup Light or Surge Brake Lockout Circuit

Enhance the safety and reliability of your marine electrical system with the ModuLite® HD Protector. Specifically engineered for boating applications, this advanced protector ensures seamless trailer connections by preventing electrical shorts, overloads, and other potential issues, allowing you to focus on enjoying your time on the water.

Key Features

• High Current Ratings:

  Circuit	Maximum Amps
  Turns/Stops	4.2 A
  Taillight	7.5 A
  Back-Up	4.2 A

• Efficient Power Usage: Draws power directly from the vehicle battery while consuming less than 5mA for sensing trailer functions on and off.
• Versatile Bulb Compatibility: Compatible with both LED and incandescent bulbs for optimal performance on both vehicle and trailer lighting.
• Advanced Protection: Integrated re-settable short circuit and overload protection safeguard both the protector and your boat’s electrical system from shorts and wiring mishaps.
• Seamless Integration: Designed to prevent feedback through the vehicle circuits, ensuring stable and reliable operation.
• Brake Override: Trailer brakes automatically override hazard lamps when the brake is activated, enhancing safety during maneuvers.
• PWM Compatible: The taillight circuit is upgraded to work with pulse width modulation (PWM) systems, ensuring full brightness of trailer lights during activation.
• Multiplex System Support: Compatible with most vehicles equipped with multiplex lighting systems.
• Connector Integration: Features an integrated 5-flat electrical wiring connector, allowing for additional circuits such as surge brake lockout or backup light. Some units include a 5-way cap; mounting brackets are sold separately.
• Flexible Wiring: Suitable for both 2-wire and 3-wire systems, providing versatility in installation.
• Durable Construction: All solid-state components are encapsulated in potting to protect against moisture and corrosion, ideal for marine environments.
• Protective Cover: Includes an integrated protective cover to shield the unit from harsh marine conditions.

Technical Specifications

Specification	Details
Power Source	Directly from vehicle battery
Current Rating	4.2 A (Turns/Stops), 7.5 A (Taillight), 4.2 A (Back-Up)
Power Consumption	Less than 5mA for sensing
Bulb Compatibility	LED and Incandescent
Connector Type	5-flat electrical wiring connector
Wiring Compatibility	2-wire and 3-wire systems
Protection Features	Resettable Short Circuit and Overload Protection
Additional Features	Integrated protective cover, PWM compatible, multiplex system support

Compatibility

The ModuLite® HD Protector is designed to work with a wide range of marine vehicles that feature multiplex lighting systems. It is not compatible with vehicles that utilize a low-side switch. Ensure your boat's electrical system meets these requirements for optimal performance.

Installation

Installing the ModuLite® HD Protector is straightforward, whether you are working with a 2-wire or 3-wire system. The integrated 5-flat connector simplifies the wiring process, and mounting brackets are available separately for secure placement on your vessel. Follow the included instructions to connect the unit directly to your vehicle’s battery and trailer circuits.

Safety Information

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
