T-Spec VPNB4 MANL 4 Position All-In-One Distribution Block w/Cover

Efficiently manage your boat's electrical system with the VPNB4 MANL 4 Position All-In-One Distribution Block. Designed specifically for marine applications, this robust distribution block ensures safe and reliable power distribution across multiple sources, maintaining optimal performance even in harsh marine environments.

Product Description

The T-Spec VPNB4 distribution block is engineered to handle high-current power and ground distribution for four independent power sources. Each power source is safeguarded with a mini-ANL fuse, providing enhanced protection against electrical overloads. This compact yet durable block allows power distribution from a single 1/0-gauge positive power cable to four separate 4 to 8 gauge power leads, each protected by its own fuse. Additionally, the VPNB4 consolidates two ground wires into a single 1/0 to 4 gauge ground cable, ensuring a stable and efficient grounding system for your marine vessel.

Note: Fuses are sold separately.

Features

Input	Output
(2 positive) 1/0 to 4 AWG	(4 positives) 4/8 AWG
(1 negative) 1/0 to 4 AWG	(4 negatives) 4/8 AWG

• TPE wrapped for a soft touch
• Dual sizes gasket set for versatile installation
• Water-resistant design suitable for marine environments
• Constructed from solid brass for durability
• Finished with black nickel for corrosion resistance
• Secure mounting with T20 Torx® screws
• Enhanced security with Gate Lock technology

What's Included

• Distribution block for both power and ground
• Plastic cover (attached)
• 3 rubber grommets and sleeves on power inputs (installed)
• 2 rubber grommets and sleeves on power outputs (installed)

Sold individually.
