Pacer Group  |  SKU: LOS-102502  |  Barcode: 840248214971

Pacer DT Deutsch Plug Repair Kit - 14-18 AWG (3 Position)

$5.99 USD $7.78

Product Description

Ensure reliable and secure electrical connections on your vessel with Pacer's DT Deutsch Plug Repair Kit. Specifically designed for marine and boating applications, this kit accommodates 14-18 AWG wires, providing durability and performance even in harsh marine environments.

Product Overview

The DT Deutsch Plug Repair Kit by Pacer features robust 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) ideal for 14 AWG wires commonly used in marine electrical systems. The versatile DT series connectors support wire gauges ranging from 20 to 14 AWG, each offering a 13-amp continuous capacity within a single, compact shell. This adaptability makes the DT series a preferred choice for marine electrical designers seeking flexibility and reliability.

Features

  • Packs contain all necessary components to assemble a complete connector
  • Includes one to two extra terminals for additional connections
  • Cavity plugs available to seal open circuits, enhancing waterproofing

Applications

  • Ideal for wire-to-wire connections on boats and yachts
  • Enclosed connectors provide field-proven reliability and rugged quality, perfect for marine environments

Compliance

Standard Details
Ingress Protection (IP) IP68 and IP6K9K
Environmental EU RoHS/ELV compliant
Flammability Standard UL-94 Recognized

Product Characteristics

  • Wedge locks ensure precise contact alignment and secure retention
  • Redundant silicone seals provide enhanced waterproofing and durability
  • Contacts are hand-insertable and removable for easy maintenance and repairs

Technical Specifications

Specification Details
Number of Cavities 3
Housing Rectangular receptacle, plastic reinforced with glass fiber
Contact Size 16 (13 amp)
Wire Size 14 AWG
Holds Pin/Socket Sockets
Operating Temperature -55°C to 125°C

Package Contents

  • 1 x 3-position plug
  • 1 x 3-position wedge lock
  • 4 x sockets
  • 1 x cavity plug

Download Quick Guide (PDF)
