Jabsco Par-Max HD4 Heavy Duty Water Pressure Pump - 12V - 4 GPM - 40 PSI
Jabsco Par-Max HD4 Heavy Duty Water Pressure Pump - 12V - 4 GPM - 40 PSI is backordered and will ship as soon as it is back in stock.
Product Description
Product Description
The Par-Max HD4 Heavy Duty Water Pressure Pump is engineered for marine and boating applications, delivering reliable performance with 12V power, 4 GPM flow rate, and 40 PSI pressure. Designed to withstand the demanding conditions of marine environments, this pump ensures consistent water pressure for all your onboard needs.
Exceptional Performance for Marine Applications
The HD4 model features a robust motor with a wider diameter and a powder-coated shell, enhancing both pressure capability and longevity. Constructed with cast aluminum endbells and a lower housing, this pump is built to endure high-pressure operations, making it ideal for various marine setups.
Versatile Configurations
Available in configurations up to 6 GPM (23 LPM) and 60 PSI (4.1 BAR), the Par-Max HD4 delivers outstanding performance tailored to your vessel's requirements. The standard models offer reliable performance in a compact, economical design, available in 1-3 GPM options to suit boats with 1-3 outlets. The plastic housing on standard models protects the motor from corrosive marine environments.
Key Features
- Durable Construction: Co-molded diaphragm technology ensures long life and reliability.
- Heavy Duty Motors: HD models come with robust motors and cast aluminum lower housings for extended lifespan, even under high pressure.
- Quiet and Efficient: Designed for efficient and quiet operation to minimize noise on board.
- Integrated Pressure Switch: Sealed pressure switch allows for on-demand operation, optimizing performance.
- Self-Priming Capability: Enables flexible installation options, adapting to various marine setups.
- Dry Run Protection: Can operate without water without sustaining damage.
- Easy Installation: Quick connect ports simplify installation, servicing, and maintenance.
- Vibration Dampening: Mounting feet reduce vibrations, enhancing pump stability and longevity.
- Smoother Flow: Integrated bypass module minimizes cycling and ensures a consistent water flow.
Technical Specifications
| Motor Design | Brushed, permanent magnet TENV |
|---|---|
| Pumphead Upper Housing Material | Glass fiber reinforced polypropylene |
| Diaphragm | Co-molded TPV |
| Check Valves | EPDM |
| Max Inlet Pressure | 30 PSI (2.1 Bar) |
| Fluid Temperature Range | 32°F – 140°F (0°C – 60°C) |
| Dry Self-Priming Capability | 7ft min (2.13m/min) |
| Certifications | CE, ISO8846, RCM |
| Ingress Protection | IPX6 |
Additional Specifications
| Voltage | 12V |
|---|---|
| Maximum PSI | 40 |
| Gallons Per Minute | 4 GPM |
| Box Dimensions | 5"H x 6"W x 15"L |
| Weight | 7.85 lbs |
| UPC | 671880841863 |
WARNING: This product can expose you to chemicals including ANTIMONY OXIDE (ANTIMONY TRIOXIDE) which is known to the State of California to cause cancer. For more information, visit P65Warnings.ca.gov.
