Jabsco Par-Max 3 Water Pressure Pump - 24V - 3 GPM - 40 PSI
Jabsco Par-Max 3 Water Pressure Pump - 24V - 3 GPM - 40 PSI is backordered and will ship as soon as it is back in stock.
Product Description
Product Description
The Par-Max 3 Water Pressure Pump is engineered for marine and boating enthusiasts, delivering reliable 24V performance with a flow rate of 3 GPM and a maximum pressure of 40 PSI. Whether you're navigating open waters or enjoying a day on the lake, this pump ensures consistent water flow to meet all your vessel’s needs.
Key Features
- Durable Construction: Heavy-duty models come with a wider diameter motor, powder-coated shell, cast aluminum endbells, and a reinforced lower housing, enhancing both pressure capability and longevity.
- Versatile Performance: Available in configurations up to 6 GPM (23 LPM) and 60 PSI (4.1 BAR), providing exceptional water flow and pressure for various marine applications.
- Quiet and Efficient Operation: Designed to operate smoothly with minimal noise, ensuring a comfortable boating experience.
- Integrated Pressure Switch: Sealed pressure switch allows for on-demand operation, maintaining optimal water pressure without unnecessary cycling.
- Self-Priming Capability: Facilitates flexible installation options and ensures reliable performance even after dry runs.
- Corrosion-Resistant Housing: Standard models feature a plastic housing that protects the motor from the harsh marine environment.
- Easy Installation and Maintenance: Quick connect ports simplify the installation process and make servicing and maintenance straightforward.
- Vibration Dampening Mounts: Specialized mounting feet reduce vibrations, enhancing pump stability and extending its lifespan.
- Integrated Bypass Module: Reduces cycling frequency and provides a smoother water flow for enhanced comfort onboard.
Technical Specifications
| Parameter | Details |
|---|---|
| Voltage | 24V |
| Flow Rate | 3 GPM (Gallons Per Minute) |
| Maximum Pressure | 40 PSI |
| Motor Design | Brushed, Permanent Magnet TENV |
| Pumphead Material | Glass Fiber Reinforced Polypropylene |
| Diaphragm | Co-molded TPV |
| Check Valves | EPDM |
| Maximum Inlet Pressure | 30 PSI (2.1 Bar) |
| Fluid Temperature Range | 32°F – 140°F (0°C – 60°C) |
| Dry Self-Priming Capability | 7 ft min (2.13 m/min) |
| Certifications | CE, ISO8846, RCM |
| Ingress Protection | IPX6 |
| Box Dimensions | 6"H x 6"W x 16"L |
| Weight | 4.9 lbs |
| UPC | 671880841825 |
Safety Information
WARNING: This product can expose you to chemicals including ANTIMONY OXIDE (ANTIMONY TRIOXIDE) which is known to the State of California to cause cancer. For more information, visit P65Warnings.ca.gov.
