Blue Sea 8043 AC Main +3 Positions Toggle Circuit Breaker Panel - White Switches

Ensure your marine electrical system operates safely and efficiently with the 8043 AC Main +3 Positions Toggle Circuit Breaker Panel - White Switches. Specifically designed for boating and marine applications, this robust circuit breaker panel provides reliable protection and easy monitoring of your vessel's electrical circuits, enhancing both safety and performance on the water.

Key Features

• Red reverse polarity indicating LED for enhanced safety
• Fully pre-wired with all hot, neutral, and safety ground buses installed
• Backlit circuit label positions on standard panels – no additional kit required
• "ON" indicating LEDs installed in all circuit positions for clear status indication

Technical Specifications

Feature	Details
Number of Positions	3
Nominal Voltage	120v AC
Box Height	7.5"
Box Width	5.25"
Box Depth	10"
Weight	5.6 lbs
UPC	632085080433
AC/DC	AC
Maximum Breaker Quantity	3

Included Components

• (1) 8031 Basic AC Panel Label Set - 30 Labels
• (4) 8034 LED - 120v AC Green
• (1) 8066 LED - 120v AC Red
• (3) 7210 A-Series White Toggle Circuit Breaker - Single Pole 15A (Branch)
• (1) 7238 A-Series White Toggle Circuit Breaker - Double Pole 30A (Main)
• (1) 9353 AC Voltmeter - 0 to 150v AC (Meter)

Safety Information

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.

Additional Resources

Owner's Manual (PDF)
