Ancor 22-18 Female Heatshrink Snap Plug - 100-Pack

Ensure reliable and durable electrical connections on your vessel with our 22-18 Female Heatshrink Snap Plug. Designed specifically for marine and boating applications, this 100-pack provides superior protection against harsh marine environments, ensuring your electrical systems remain secure and efficient.

Features

• Superior Material: Constructed with cross-linked polyolefin tubing, offering enhanced strength and flame resistance compared to traditional PVC tubing.
• Advanced Sealing: Heat-activated adhesive lining creates an impervious seal against salt water, oil, acids, and sunlight, providing effective strain relief.
• Marine-Grade Insulation: Equipped with a nylon insulator, trusted by experts for its resistance to sunlight, water, oil, chemicals, vibration, and cut-through damage.
• Certified Safety: UL Listed and CSA Recognized, ensuring compliance with industry safety standards.
• High Shrink Ratio: Shrinks to one-third of the original size at 257°F (125°C), offering a compact and secure fit.
• Optimal Operating Range: Functions effectively within a temperature range of 40°C to 110°C.
• Integrated Adhesive: ANCOR heat shrink connectors feature built-in heat-activated adhesive for a watertight seal and superior vibration and strain relief.
• Corrosion Resistant: Tinned for enhanced resistance to corrosion in marine environments.
• High Conductivity: Made with pure copper to ensure maximum current flow.
• Durable Construction: Features a brazed seam for added strength and longevity.
• Wire Compatibility: Suitable for wires ranging from 22-18 AWG (.157).
• Size Specifications: Available in sizes ranging from 0.3-0.8mm to 4mm.
• Gender: Female connectors for secure mating.
• Package Quantity: Comes in a convenient pack of 100 units.

Specifications

Type	Snap Plugs
Gauge	22-18 AWG
Package Quantity	100
Heat Shrink	Yes
Box Dimensions	3"H x 3"W x 9"L
Weight	0.3 lbs
UPC	091887807639

Additional Resources

Quick Guide (PDF)

Safety Information

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.
